LUXA 103-200 T

Description

Motion detector (PIR)
Automatic lighting control based on presence and brightness
Wall installation
Compatible with branded switches, replaces conventional light switches
2 wire connection, ideal for retrofitting
Light switch output (triac, 230 V AC)
Mixed light measurement suitable for incandescent and halogen lamps (no electronic ballast)
Area limit via lens attachment
Manual AUTO/ON/OFF switching by simple adjustment of cover flap
Teach-in of current brightness value
Advance shut-off warning through dimming 15 seconds before light switches off
Instant start-up possible via factory preset
No unintentional adjustment due to covered up controls
Adjustable brightness switching value and switch-off delay
Sensitivity can be reduced to limit detection area
Pulse function
Test function

Operating voltage	230 V AC
Frequency	50 Hz
Stand-by consumption	~0,7 W
Light measurement	Mixed light measurement
Number of channels	1
Type of contact	Triac
Installation type	Flush-mounted wall installation
Setting range brightness	10聽鈥撀�1000 lx Infinitely adjustable
Switching capacity light	2 A (at 230 V AC, cos 蠁 = 1),
Detection angle	200掳, circular
Recommended installation height	1,2聽鈥撀�2 m
Light switch-off delay聽	20 s鈥�30 min
Incandescent lamp load	400 W
Lamps	Incandescent/halogen lamps
Ambient temperature	+0 掳C聽鈥β�+45 掳C
Protection class	II
Type of protection	IP 40
