| Operating voltage |
230 V AC |
| Frequency |
45聽鈥撀60 Hz |
| Number of channels |
1 |
| Width |
3 modules |
| Installation type |
DIN rail |
| Type of connection |
Screw terminals |
|
Drive
|
Quartz-controlled stepper motor |
| Program |
Daily/weekly program with 1/2 day OFF function |
| Power reserve |
3 days |
| Switching capacity at 250 V AC, cos 蠁 = 1 |
10 A |
| Switching capacity at 250 V AC, cos 蠁 = 0,6 |
4 A |
| Shortest switching times |
45 min, 12 h |
| Programmable every |
15 min, 12 h |
| Time accuracy at 25 掳C |
鈮 卤 1 s/day (quartz) |
| Type of contact |
Changeover contact |
| Switching output |
Potential-free and phase-independent |
| Stand-by consumption |
0,5 W |
| Test approval |
VDE |
| Housing and insulation material |
High-temperature resistant, self-extinguishing thermoplastic |
| Type of protection |
IP 20 |
| Protection class |
II according to EN 60 730-1 |
| Ambient temperature |
-20 掳C聽鈥β+55 掳C |
